Build

Frame

28″, super lite AL-6061 tubing, BES III, PowerTube battery

BB Standard: Bosch, Press Fit

Color: Matt Titanium Silver

Fork

Suntour NVX30 DS, 75 mm

Travel: 75mm

Spring Type: Coil

Bottom Bracket

Bosch, Isis

Headset

Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing

Stem

Satori Python, adjustable

Handlebar

BGM Pro, riserbar, backsweep: 15, rise: 5 mm

Saddle

Syncros Capilano Trekking Memory Foam

Seatpost

BGM Pro

Type: Rigid

Pedals

Marwi SP-890 matt Sandblock

Grips

BGM Comfort, Ergo, double density, clamp version

Groupset

Rear Derailleur

Shimano Deore Linkglide, RD-M5130, Shadow Plus

Crank

FSA CK-320, 38t

Shifters

Shimano Deore Linkglide, SL-M5130, 1×10-speed, rapidfire plus-shifter

Cassette

Shimano Linkglide, CS-LG600-10, 11-43t

Chain

Shimano Linkglide, CN-LG500

Brakes

Shimano BR-MT200, hydraulic disc brake

Type: Hydraulic Disc

Brake Levers

Shimano BL-MT201, hydraulic disc brake

Wheels

Rims

Ryde Rival 23 disc, eyelets

Spokes

Sapim Leader

Front Hub

Shimano HB-MT200, centerlock, disc, quick release

Rear Hub

Shimano, centerlock, disc, quick release

Tires

Front: Schwalbe Energizer Plus Tour, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19, Rear: Schwalbe Energizer Plus Tour, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19

Disc Rotors

Shimano SM-RT10, 180 mm

Electric Components

Motor

Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h

Battery

Bosch PowerTube, 36 V Li Ion, 625 Wh

Display

Bosch LED Remote with Intuvia 100 display

Charger

Bosch Standard Charger, 4A

Accessories

Lights

Front: B&M Dopp, 35 Lux, LED Rear: B&M Toplight 2 C, LED

Fenders

Curana Apollo, with stainless stays

Racks

Racktime / BGM Trekking Pro, Snapit 2.0 System, integrated fender mount
