Build
| Frame | e-VERTIC C-Type ALU sizes: 43, 48, 53 – 9×135 mm quick release dropouts – Post mount 180 disc brake type BB Standard: Bosch, Press Fit Colors: T5 – Champagne / Graphite Race Matt; T6 – Blue Grey / Graphite Race Matt |
|---|---|
| Fork | Suntour 29″, travel 100mm, COIL w/Preload adjuster, CR plating, Pitch 130 mm, 1-1/8″(TS), OLD 9-100, max rotor 180, post mount 160mm direct Travel: 100mm Spring Type: Coil |
| Bottom Bracket | included in the motor |
| Headset | SeatpLock SET AL bk T-Tronik + Omnia Screw M5x40, CH, hex, black Seatclamp Rubber Cover Omnia |
| Stem | Velomann, 28,6 mm steerer ID Clamp, 31,8 mm barbore |
| Handlebar | Velomann 31.8/680mm, RISE 20MM, SWEEP 15 |
| Saddle | Velomann, steel rail, black cover 8067, 254x183mm, 420gr. |
| Seatpost | Velomann, lenght 350mm for SM size and 400mm for MD, LG, diam.31,6mm, 0mm seatback Type: Rigid |
| Grips | Herrmans, 130mm/130mm, d.22mm |
Groupset
| Rear Derailleur | SRAM RD X7 SHORT CAGE ALUMINUM 9sp |
|---|---|
| Crank | FSA E-Bike Diecast Crankset – CK220 Gen 3 / 170mm / Die cast aluminum FSA Direct Mount Steel Chainring – 38T / w/HT Steel / ED / C.L. 50mm Bosch Gen3 Bolt – Bosch Gen3 crank bolt Black |
| Shifters | SRAM X5 TRIGGER REAR 9-SPD BLK 2200MM CABLE |
| Chain | KMC e9S NPBK 1/2″ x 11/128″ |
| Brakes | Shimano, BL-MT200, BR-MT200, BLACK, SM-MA-F180P/P2, RESIN PAD, 1000MM HOSE / 1700 HOSE Type: Hydraulic Disc |
