Build
| Frame | eONE-FORTY LITE III, material: aluminium, 133mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, MUK 37 Hanger BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork | FOX Rhythm 34 Float eMTB+, Air, 140mm suspension travel, Tapered, 51mm fork offset, 29×2.5″ max wheelsize Travel:Â 140mm Spring Type:Â Air |
| Shock | Rock Shox Deluxe Select+, platform Travel:Â 133mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | MERIDA 8152 |
| Stem | MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0 stem angle, GoPro & Supernova mount, 50 mm |
| Handlebar | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle | MERIDA EXPERT CC, V-mount, incl. MERIDA minitool |
| Seatpost | MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S 100mm travel seatpost – S/M 125mm travel seatpost – L 150mm travel seatpost – XL/XXL 170mm travel seatpost Type:Â Dropper |
| Pedals | VP VPE-527 |
Groupset
| Rear Derailleur | Shimano XT RDM8100 Shadow+ 12 |
|---|---|
| Crank | Shimano CRE80-12-B, 34 teeth |
| Shifters | Shimano SL -MT500-IL / Shimano Deore M6100 |
| Cassette | Shimano M6100, 10-51 teeth, 12 speed |
| Chain | KMC e12T EPT |
| Brakes | Shimano SLX, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims | MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Maxxis Rekon, 29×2.4″, fold, 3C EXO MaxxTerra, Rear: Maxxis Rekon, 27.5×2.6″, fold, TR 3C EXO MaxxTerra |
| Disc Rotors | Shimano RT64 / Shimano RTEM600, 203 mm |
Electric Components
| Motor | Shimano EP8, 85Nm |
|---|---|
| Battery | Shimano E8036 630Wh / Shimano E8035 504Wh for S only |
| Display | Shimano SC-E7000 |
| Charger | Shimano EC-E8004, 4A charging current |
Accessories
| Lights | Lezyne E-Bike Power E115 / Dlight CG-214RG, StVZO, reverse MERIDA Custom Mount, STVZO, USB |
|---|---|
| Fenders | C093-02F + C093-02R |
