Build
| Frame | eONE-SIXTY LITE III, material: aluminium, 150mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, intube BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork | Rock Shox 35 Gold RL, Air, 160mm suspension travel, Tapered, 51mm fork offset, 29×2.8″ max wheelsize Travel:Â 160mm Spring Type:Â Air |
| Shock | Rock Shox Deluxe Select+, platform Travel:Â 150mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | MERIDA-8152 |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle | MERIDA COMP SL, V-mount |
| Seatpost | MERIDA COMP TR, 30.9mm diameter, 0mm setback, XS/S 100mm travel seatpost – M/L 125mm travel seatpost – XL 150mm travel seatpost Type:Â Dropper |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | Shimano Deore RDM5100 11 |
|---|---|
| Crank | Shimano CRE70-B, 34 teeth |
| Shifters | Shimano SL -MT500-IL / Shimano Deore M5100 11 |
| Cassette | Shimano M5100, 11-51 teeth, 11 speed |
| Chain | KMC e11S EPT |
| Brakes | Shimano M4204, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Kenda Regolith, 29×2.4″, wire, Rear: Kenda Regolith, 27.5×2.6″, wire |
| Disc Rotors | Shimano RT30 / Shimano RTEM300, 203 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Shimano EN806, 630Wh Shimano EN805 504Wh for XS only |
| Display | Shimano SC-EN600 |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount / USB REAR Light CG-214RG |
|---|---|
| Fenders | C093-02F + C093-02R |
