| Frame | Aluminium 6061 TFW, Motor mount: Shimano, Cable routing: partially integrated, Axle mount I: thru axle 12×142 mm, Axle mount II: hub gear 135 mm, Brake: Postmount Disc 160, Tire clearance: 55 mm with plates, mudguard and luggage carrier eyelets BB Standard: STEPS, Press Fit |
|---|---|
| Fork | Suntour Mobie E25 LO, axle mount: thru axle 15×100 mm, steerer tube: 1 1/8in to 1.5in, travel: 75 mm, suspension: steel spring, damping adjustment: lockout, max. tire width: 55 mm, disc brake mount Travel: 75mm |
| Bottom Bracket | STEPS, press-fit |
| Stem | TRENGA aluminum rigid, length: depending on frame height, fork clamp : 28.6 mm, handlebar clamp : 31.8 mm, angle: 17 |
| Saddle | Selle Italia ST-3, Designed with a focus on comfort, perfect for everyday riders, Large SUPERFLOW opening relieves the perineal area, Gel padding with Soft-Tek cover, Hi-Viz inserts increase visibility in the dark |
| Seatpost | TRENGA aluminium rigid, diameter: 30.9 mm, length: 400 mm, clamping: 2-way, offset: 10 mm Type: Rigid |
| Pedals | TRENGA C016, Large, rubberized tread, aluminum pedal body, reflectors |
| Rear Derailleur | Shimano Deore RD-M5130 SGS, Shadow RD Plus design for optimal chain guidance, Optimized for LINKGLIDE, Smooth and reliable shifting, Stabilizer reduces chain slap, Largest pinion max. 43 teeth |
|---|---|
| Crank | Shimano Steps FC-EM600, Specially developed for e-bikes, Crank length: 165 mm or 170 mm, depending on frame height, Q-factor: 177 mm, Robust 24 mm bottom bracket axle |
| Shifters | Shimano Deore SL-M5130, Rapidfire Plus – smooth, fast shifting, variable I-SPEC EV mounting, optical gear display, 2-way release allows shifting with thumb or index finger |
| Cassette | Shimano CS-LG400-10, 10-speed LINKGLIDE, gradation: 11-13-15-17-20-23-26-30-36-43, increased wear resistance |
| Chain | Shimano CN-HG601, HG-X 11-speed, optimized shifting behavior, dirt-repellent design, SIL-TEC coating for longer durability |
| Brakes | Shimano BR-MT402, hydraulic disc brake, reliable brake control, brake lever: BL-MT402 3-finger, brake calliper: BR-MT410 2-piston, brake pad: B05S-RX Resin Type: Shimano Deore Hydraulic Disc |
| Rims | Ryde Andra 321, light and stable, ideal for modern e-bikes, 36 hole, ETRTO: 21-622 |
|---|---|
| Tires | Schwalbe Marathon E-Plus Reflex, Size: 50-622, Especially for e-bikes, Grippy, durable ADDIX-E compound, Puncture-proof thanks to Smart DualGuard, Reflective strips |
| Motor | Shimano STEPS EP600, Max. torque: 85 Nm, Rated continuous power: 250 W, Light, quiet and compact, Configurable via E-TUBE-PROJECT app |
|---|---|
| Battery | Shimano BT-EN605, integrated on the down tube, voltage: 36V, capacity: 14 Ah, energy content: approx. 504 Wh, weight: approx. 2.6 kg |
| Display | Shimano Steps SC-EN 610, Large 2.8 color LCD display, Quick display change, Customizable display via E-TUBE app, Variable mounting |
| Charger | STEPS charger Shi EC-E8004, charging current (max.): 4.6 A, battery charging voltage: 42 V, size: 160 x 70 x 44 mm, weight: including cable approx. 450 g, charging time: 4 h for 504 Wh battery, approx. 4.8 h for 630 Wh battery |
| Lights | Rear: Busch & Mller Toplight 2-C, LED rear light for luggage carrier mounting, LINE-TEC light clamps, integrated Z-large area reflector |
|---|---|
| Fenders | SKS Bluemels matt black, sandwich construction made of aluminum/plastic, robust, rigid and corrosion-resistant, innovative light cable routing system, ASR safety system, width: 60 mm, max. tire width: 50 mm |
| Racks | Racktime Stand-It, SNAPIT compatible, load capacity: 25 kg, spring clamp can be easily retrofitted, material: aluminum |
| Lock | Abus battery lock, Abus PLUS battery lock against battery theft |
| Stand | Hebie rear triangle 661, material: steel, coated, wide base for secure stand, load capacity up to 25 kg, stepless length adjustment without tools, dropout direct mounting KSA 40 |
| Bell | TRENGA Single Bell, Material: Aluminium, Bell clapper rotatable, Loud and sonorous |
