Build
| Frame | Ari Wire Peak 2.0 Full Suspension, 145mm travel. UDH derailleur hanger. Hanger Standard: UDH Colors: Maroon Flame; Desert Silk |
|---|---|
| Fork | Fox Float 36 Grip 2 160mm, Performance Elite, External high-speed compression, low-speed compression, rebound, 160mm, 15×110,44mm offset Travel: 160mm Spring Type: Air |
| Shock | Fox Float X Performance Elite, 210×55, Custom Tuned Travel: 145mm |
| Headset | FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered, with 10mm lower cup |
| Stem | Ari Charger CNC 35 stem |
| Handlebar | Ari Team 35, width 780/800mm, 25mm rise, 9 back sweep, 5 Up sweep, bar-customized sizing through 23-Point Custom Setup |
| Saddle | Selle Italia X3 Boost 148 |
| Seatpost | TranzX JD-YSI05J w/ Travel Adj. Dropper- customized sizing through 23-Point Custom Setup Type: Dropper |
| Pedals | Available Separately |
Groupset
| Rear Derailleur | Shimano XT Linkglide, 11-Speed |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano FC-EM600, 160mm |
| Shifters | Shimano XT Linkglide, Trigger 11-Speed |
| Cassette | Shimano XT Linkglide, 11-50T 11-Speed |
| Chain | Shimano CN-LG500, 11-Speed |
| Brakes | TRP Trail EVO, HD-M843, 2.3mm 203/203 F/R rotors Type: Hydraulic Disc |
Wheels
| Rims | DT Swiss H 1900 Spline, 32 hole, Disc, Tubeless Ready |
|---|---|
| Spokes | DT Swiss Hybrid 1 Straightpull |
| Front Hub | F: DT Swiss 370 E-Specific, Disc, 15×110 thru axle, R: DT Swiss 370 Ratchet LN 18 E-Specific, Disc, 12×148 thru axle, HG |
| Rear Hub | F: DT Swiss 370 E-Specific, Disc, 15×110 thru axle, R: DT Swiss 370 Ratchet LN 18 E-Specific, Disc, 12×148 thru axle, HG |
| Tires | Front: Maxxis Minion DHF 29X2.5 WT Exo Tubeless Ready 60 TPI, Rear: Maxxis Dissector 29X2.4 Exo Tubeless Ready |
Electric Components
| Motor | Shimano EP6 Ari custom motor tune |
|---|---|
| Battery | Darfon 36V, 635Wh Group B EP6/EP801 |
